CLAW COUPLING KIG FEMALE THREAD - SS 316

CLAW COUPLING KIG WITH FEMALE THREAD STAINLESS STEEL 316 VITON INPART24
MATERIAL: SS 316 | WORK PRESSURE: 16 BAR | SEALING RING: VITON (FKM) | NORM: DIN 3489 | CLAW DISTANCE: 42 MM

Product params

Material

SS 316

Sealing ring

Viton

Norm

DIN 3489

Claw coupling KIG for pneumatic power supply, with inner thread, made of stainless steel, according to DIN 3489 norm.

Material: stainless steel SS 316

Sealing ring: Viton

Work pressure: 16 BAR

Norm: DIN 3498

Size chart

Variant

Lug distance [mm]

Material

Thread connection

Seal material

Min. medium temp. [°C]

Max. medium temp. [°C]

Work Pressure - BAR [20°C]

Weight [g]

Trade unit

Variant

Lug distance [mm]

Material

Thread connection

Seal material

Min. medium temp. [°C]

Max. medium temp. [°C]

Work Pressure - BAR [20°C]

Weight [g]

Trade unit

Variant

2183

Lug distance [mm]

42

Material

SS 316

Thread connection

3/8'' Female

Seal material

Viton

Min. medium temp. [°C]

-40

Max. medium temp. [°C]

95

Work Pressure - BAR [20°C]

16

Weight [g]

170

Trade unit

pcs

Variant

2184

Lug distance [mm]

42

Material

SS 316

Thread connection

1/2'' Female

Seal material

Viton

Min. medium temp. [°C]

-40

Max. medium temp. [°C]

95

Work Pressure - BAR [20°C]

16

Weight [g]

155

Trade unit

pcs

Variant

2185

Lug distance [mm]

42

Material

SS 316

Thread connection

3/4'' Female

Seal material

Viton

Min. medium temp. [°C]

-40

Max. medium temp. [°C]

95

Work Pressure - BAR [20°C]

16

Weight [g]

145

Trade unit

pcs

Variant

2189

Lug distance [mm]

42

Material

SS 316

Thread connection

1'' Female

Seal material

Viton

Min. medium temp. [°C]

-40

Max. medium temp. [°C]

95

Work Pressure - BAR [20°C]

16

Weight [g]

180

Trade unit

psc
