ALIMFOOD BIOTEX SD PVC HOSE FDA
Suction and discharge hose | Reinforcement: polyester reinforcement, steel spiral | Inner wall: PVC | Outer wall: PVC | Working pressure: 12-20 BAR | Temperature range: -10 to +60 °C | Conduction: R<10² Ω/m
Product params
Working Pressure [bar]
12-20
Inner Wall
PVC
Conduction
R<10² Ω/m
Thermoplastic PVC food hose with polyester yarn reinforced and steel spiral. Suitable for the beverage, juices, milk, and alcohol up to 50%. Thanks to additional polyester reinforced, the hose performance of work pressure is better than classic PVC hose with spiral (e.g. ALIMFOOD SD PVC ).
Inner wall: PVC - transparent
Outer wall: PVC - transparent
Reinforcement: polyester reinforcement, steel spiral
Working pressure: 10-20 BAR
Temperature range: -10°C to +60°C
Conduction: R<10² Ω/m
Norms: EU 10/2011, FDA CFR 21 item 176.170
Size chart
Variant
Inner Diameter [mm]
Outer Diameter [mm]
Work Pressure - BAR [20°C]
Burst Pressure - BAR [20°C]
Coil [mtr]
Vacuum
Bending Radius [mm]
Weight [g]
Variant
Inner Diameter [mm]
Outer Diameter [mm]
Work Pressure - BAR [20°C]
Burst Pressure - BAR [20°C]
Coil [mtr]
Vacuum
Bending Radius [mm]
Weight [g]
Availability
Variant43109
Inner Diameter [mm]25
Outer Diameter [mm]32
Work Pressure - BAR [20°C]12
Burst Pressure - BAR [20°C]36
Coil [mtr]60
Vacuum100%
Bending Radius [mm]75
Weight [g]650
Availability
🔍
Variant43110
Inner Diameter [mm]32
Outer Diameter [mm]43
Work Pressure - BAR [20°C]11
Burst Pressure - BAR [20°C]33
Coil [mtr]61
Vacuum90%
Bending Radius [mm]96
Weight [g]880
Availability
🔍
Variant43111
Inner Diameter [mm]38
Outer Diameter [mm]49
Work Pressure - BAR [20°C]10
Burst Pressure - BAR [20°C]33
Coil [mtr]30
Vacuum90%
Bending Radius [mm]110
Weight [g]1025
Availability
🔍
Variant43115
Inner Diameter [mm]50
Outer Diameter [mm]63
Work Pressure - BAR [20°C]8
Burst Pressure - BAR [20°C]24
Coil [mtr]30
Vacuum80%
Bending Radius [mm]150
Weight [g]1640
Availability
🔍
