CAMLOCK COUPLING TYPE AWB - SS 316

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24
CAMLOCK COUPLING TYPE AWB | BUTT WELD | 18 BAR | AISI 316

Product params

Material

Aluminum

Sealing Ring

NBR

Male CAMLOCK coupling type AWB with butt weld. Made in accordance with the US norm MIL-C-27847 (A-A-59326). It is one of the most popular quick coupling systems used in Europe's industrial applications. These couplings are designed for quick and safe connections between the hose and the installation and find applications in transfer systems, the chemical industry, and many other industrial sectors.

Size chart
Variant
Size
Material
Welding size [mm]
Work Pressure - BAR [20°C]
Weight [kg]
CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB015SS
VariantAWB015SS
Size1/2" (DN15)
MaterialSS316
Welding size [mm]21,3
Work Pressure - BAR [20°C]18
Weight [kg]0,05
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.512.835

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB020SS
VariantAWB020SS
Size3/4" (DN20)
MaterialSS316
Welding size [mm]26,7
Work Pressure - BAR [20°C]18
Weight [kg]0,08
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.513.836

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB025SS
VariantAWB025SS
Size1" (DN25)
MaterialSS316
Welding size [mm]33,4
Work Pressure - BAR [20°C]18
Weight [kg]0,13
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.514.837

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB032SS
VariantAWB032SS
Size1 1/4" (DN32)
MaterialSS316
Welding size [mm]42,2
Work Pressure - BAR [20°C]18
Weight [kg]
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.515.838

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB040SS
VariantAWB040SS
Size1 1/2" (DN40)
MaterialSS316
Welding size [mm]48,3
Work Pressure - BAR [20°C]18
Weight [kg]0,27
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.516.839

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB050SS
VariantAWB050SS
Size2" (DN50)
MaterialSS316
Welding size [mm]60,3
Work Pressure - BAR [20°C]18
Weight [kg]0,44
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.517.840

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB065SS
VariantAWB065SS
Size2 1/2" (DN65)
MaterialSS316
Welding size [mm]76
Work Pressure - BAR [20°C]11
Weight [kg]0,59
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.518.841

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB080SS
VariantAWB080SS
Size3" (DN80)
MaterialSS316
Welding size [mm]89
Work Pressure - BAR [20°C]9
Weight [kg]0,7
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.519.842

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB100SS
VariantAWB100SS
Size4" (DN100)
MaterialSS316
Welding size [mm]114,3
Work Pressure - BAR [20°C]7
Weight [kg]1,04
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.520.843

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB125SS
VariantAWB125SS
Size5" (DN125)
MaterialSS316
Welding size [mm]139,7
Work Pressure - BAR [20°C]5
Weight [kg]2,36
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.521.844

Price vat excluded

CAMLOCK TYPE AWB MALE PART WITH BUTT WELD FOR WELDING STAINLESS STEEL AISI 316 INPART24 Variant AWB150SS
VariantAWB150SS
Size6" (DN 150)
MaterialSS316
Welding size [mm]168,3
Work Pressure - BAR [20°C]5
Weight [kg]2,89
buyRow
buyRow

Availability

Trade unit

pcs

ID

57.522.845

Price vat excluded
