AMERICA FLEX PVC HOSE
Product params
Working Pressure [bar]
Inner Wall
Conductivity
Freeze-resistant, slurry tanker, suction and discharge hose with a steel spiral. A special mixture of the PVC ensures that the hose remains very flexible even at very low external temperatures. It is suitable for use in municipal vehicles, tank trucks, and as a pipeline component. The hose is used for the transfer of fluids such as slurry, dirty water, light water-based chemicals or fecal matter.
Inner Wall: soft PVC
Outer Wall: soft PVC
Reinforcement: steel spiral
Working Pressure: 2-3 BAR (depending on the diameter)
Temperature Range: -40°C to +45°C
Size chart
id
Variant
Inner Diameter [mm]
Work Pressure - BAR [20°C]
Burst Pressure - BAR [20°C]
Bending Radius [mm]
Coil [mtr]
Outer Diameter [mm]
Vacuum [bar]
Weight gr/mtr
