MULTI-CHEM PTFE OHM SD ATEX-FDA HOSE

MULTI CHEM PTFE OHM SD ATEX FDA RUBBER HOSE FOR CHEMICALS ACIDS INPART24
Suction and discharge hose | Reinforcements: two textile reinforcements, steel spiral | Inner wall: PTFE | Outer wall: EPDM | Working Pressure: 16 BAR | Temp. Range: -40 to +150 °C

Product params

Working Pressure [bar]

16

Burst Pressure [bar]

64

Inner Wall

PTFE

Conductivity

Yes

Suction and delivery hose with PTFE inner layer for transporting the harshest high-concentration chemicals, such as sulfuric acid, phosphoric acid or solvents.

The outer layer is resistant to difficult weather conditions, including UV rays and ozone. The hose is fully conductive, i.e. R<10⁶ Ω, R<10⁹ Ω through the wall. It has food certificates allowing the hose to come into contact with food.

Hose approved for use in ATEX hazardous areas (0,1,2,20,21,22)

Inner wall: PTFE

Outer wall: EPDM

Reinforcements: two textil reinfocements, steel spiral

Work pressure: 16 BAR

Temperature range: -40°C do +150°C (depending on the medium)

Norms: USP XXXII class VI, FDA 21 CFR 177.1550, ISO 10993 sections 5,10,11:2009, EUROPEAN REGULATION 1935/2004/EC & 10/2011/CE, 3A Sanitary Standard Class II, nie toksyczny zgodnie z ISO 10993 section 5:2009

Size chart

Variant

Inner Diameter [mm]

Outer Diameter [mm]

Work Pressure - BAR [20°C]

Burst Pressure - BAR [20°C]

Vacuum - BAR [20°C]

Bending Radius [mm]

Coil [mtr]

Weight [kg/mtr]

Trade unit

Variant

Inner Diameter [mm]

Outer Diameter [mm]

Work Pressure - BAR [20°C]

Burst Pressure - BAR [20°C]

Vacuum - BAR [20°C]

Bending Radius [mm]

Coil [mtr]

Weight [kg/mtr]

Trade unit

Variant

648

Inner Diameter [mm]

13

Outer Diameter [mm]

25

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

90

Coil [mtr]

40

Weight [kg/mtr]

0,54

Trade unit

Meter

Variant

663

Inner Diameter [mm]

13

Outer Diameter [mm]

25

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

90

Coil [mtr]

40

Weight [kg/mtr]

0,54

Trade unit

Coil 40mtr

Variant

649

Inner Diameter [mm]

19

Outer Diameter [mm]

31

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

130

Coil [mtr]

40

Weight [kg/mtr]

0,7

Trade unit

Meter

Variant

662

Inner Diameter [mm]

19

Outer Diameter [mm]

31

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

130

Coil [mtr]

40

Weight [kg/mtr]

0,7

Trade unit

Coil 40mtr

Variant

650

Inner Diameter [mm]

25

Outer Diameter [mm]

37

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

170

Coil [mtr]

40

Weight [kg/mtr]

0,86

Trade unit

Meter

Variant

661

Inner Diameter [mm]

25

Outer Diameter [mm]

37

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

170

Coil [mtr]

40

Weight [kg/mtr]

0,86

Trade unit

Coil 40mtr

Variant

651

Inner Diameter [mm]

32

Outer Diameter [mm]

44

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

215

Coil [mtr]

40

Weight [kg/mtr]

1,18

Trade unit

Meter

Variant

660

Inner Diameter [mm]

32

Outer Diameter [mm]

44

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

215

Coil [mtr]

40

Weight [kg/mtr]

1,18

Trade unit

Coil 40mtr

Variant

652

Inner Diameter [mm]

38

Outer Diameter [mm]

51

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

255

Coil [mtr]

40

Weight [kg/mtr]

1,43

Trade unit

Meter

Variant

659

Inner Diameter [mm]

38

Outer Diameter [mm]

51

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

255

Coil [mtr]

40

Weight [kg/mtr]

1,43

Trade unit

Coil 40mtr

Variant

653

Inner Diameter [mm]

50

Outer Diameter [mm]

66

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

330

Coil [mtr]

40

Weight [kg/mtr]

2,08

Trade unit

Meter

Variant

658

Inner Diameter [mm]

50

Outer Diameter [mm]

66

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

330

Coil [mtr]

40

Weight [kg/mtr]

2,08

Trade unit

Coil 40mtr

Variant

654

Inner Diameter [mm]

63

Outer Diameter [mm]

79,5

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

430

Coil [mtr]

40

Weight [kg/mtr]

2,96

Trade unit

Meter

Variant

657

Inner Diameter [mm]

63

Outer Diameter [mm]

79,5

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

430

Coil [mtr]

40

Weight [kg/mtr]

2,96

Trade unit

Coil 40mtr

Variant

655

Inner Diameter [mm]

75

Outer Diameter [mm]

91

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

510

Coil [mtr]

20

Weight [kg/mtr]

3,43

Trade unit

Meter

Variant

656

Inner Diameter [mm]

75

Outer Diameter [mm]

91

Work Pressure - BAR [20°C]

16

Burst Pressure - BAR [20°C]

64

Vacuum - BAR [20°C]

0,89

Bending Radius [mm]

510

Coil [mtr]

20

Weight [kg/mtr]

3,43

Trade unit

Coil 20mtr

MULTI-CHEM PTFE OHM SD ATEX-FDA HOSE

from 879.10zł
vat excluded

intereurope shipping

Shipping all over the country

high quality

Top quality product

call us

If you have any questions, write to us

sku

SKU: 39

stock
Available
