HEAVY-MULTI 20 D HOSE

HEAVY DUTY COMPRESSED AIR RUBBER HOSE HEAVY MULTI 20 BAR D INPART24
Discharge Hose | Reinforcement: Two textile reinforcements | Inner Wall: SBR | Outer Wall: EPDM | Working Pressure: 20 BAR | Temperature Range: -30°C to +80°C

Product params

Working Pressure [bar]

20

Burst Pressure [bar]

60

Inner Wall

SBR

Conductivity

No

A highly durable, multi-purpose, discharge hose suitable for conveying compressed air (including oil-laden air), industrial water, and slurry. It is used, for example, as a high-pressure hose with claw-type connectors like ATLAS COPCO, to power pneumatic hammers, and as a pipeline component. The outer wall is resistant to UV radiation, ozone, external conditions, abrasion, and light chemicals. Thanks to the synthetic rubber blend inside, it has properties that resist wear and oil-contaminated environments.

Inner Wall: SBR

Outer Wall: EPDM

Reinforcement: Two textile reinforcements

Working Pressure: 20 BAR

Temperature Range: -30°C to +80°C

Size chart

id

Variant

Inner Diameter [mm]

Outer Diameter [mm]

Work Pressure - BAR [20°C]

Burst Pressure - BAR [20°C]

Coil [mtr]

Variant
Inner Diameter [mm]
Outer Diameter [mm]
Work Pressure - BAR [20°C]
Burst Pressure - BAR [20°C]
Coil [mtr]
Availability
Variant60001930
Inner Diameter [mm]19
Outer Diameter [mm]30
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60002537
Inner Diameter [mm]25
Outer Diameter [mm]37
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60003244
Inner Diameter [mm]32
Outer Diameter [mm]44
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60003852
Inner Diameter [mm]38
Outer Diameter [mm]52
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60005166
Inner Diameter [mm]51
Outer Diameter [mm]66
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60006379
Inner Diameter [mm]63
Outer Diameter [mm]79
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]40
Availability
🔍
Variant60007692
Inner Diameter [mm]76
Outer Diameter [mm]92
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]61
Availability
🔍
Variant60102118
Inner Diameter [mm]102
Outer Diameter [mm]118
Work Pressure - BAR [20°C]20
Burst Pressure - BAR [20°C]60
Coil [mtr]40
Availability
🔍
